PV22-6R-M

Panduit Corp
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description Pan-Term? Non-RoHS Compliant 2001 Insulated Ring Terminal Connector 26AWG 0.110 (2.79mm)
PDF
/
Inventory: 10049
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material - Insulation Vinyl

Technical

Packaging Bulk
Published 2001
Series Pan-Term?
Feature Brazed Seam
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp
ECCN Code EAR99
Color Yellow
HTS Code 8536.90.40.00
Reach Compliance Code compliant
Contact Finish Tin
Wire Gauge 22-26 AWG
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 22 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.110 (2.79mm)
Insulation Insulated
Terminal Type Circular
Stud/Tab Size 6 Stud

Dimensions

Length 17.272mm
Width 5.33mm
Thickness 0.020 0.51mm
Length - Overall 0.680 17.27mm
Width - Outer Edges 0.210 5.33mm

Compliance

Radiation Hardening No
RoHS Status Non-RoHS Compliant
