LCMDX70-12-X
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
COPPER COMPRESSION METRIC LUG,
PDF
/
Inventory: 4761
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Series LCMDX
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
HTS Code 8536.90.40.00
Contact Finish Tin
Wire Gauge 70mm2
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Ring, Tubular
Stud/Tab Size M12 Stud
Terminal Style Two Stud Holes
Dimensions
Length 105.0036mm
Length - Overall 4.134 105.00mm
Width - Outer Edges 0.965 24.51mm
Tab Thickness 0.118 3.00mm
Diameter - Barrel ID 0.531 (13.49mm)
Diameter - Barrel OD 0.650 (16.51mm)
Diameter - Ring ID 0.551 (14.00mm)
Compliance
RoHS Status RoHS Compliant
