LCMDX300-14-5
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT RING 300MM #M14
PDF
/
Inventory: 9072
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Diameter - Ring ID 0.630 (16.00mm)
Diameter - Barrel OD 1.299 (32.99mm)
Diameter - Barrel ID 1.031 (26.19mm)
Tab Thickness 0.264 6.71mm
Width - Outer Edges 1.890 48.01mm
Length - Overall 5.965 151.51mm
Length 151.511mm
Technical
Terminal Style Two Stud Holes
Stud/Tab Size M14 Stud
Terminal Type Ring, Tubular
Insulation Non-Insulated
Wire Gauge 300mm2
Contact Finish Tin
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series LCMDX
Published 2012
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
