LCMAX35-8-C
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT RING 35MM #M8
PDF
/
Inventory: 2574
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 2012
Series LCMAX
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
Contact Finish Tin
Wire Gauge 35mm2
Insulation Non-Insulated
Terminal Type Ring, Tubular
Stud/Tab Size M8 Stud
Terminal Style Single Stud Hole
Dimensions
Length 46.5074mm
Length - Overall 1.831 46.50mm
Width - Outer Edges 0.709 18.00mm
Tab Thickness 0.098 2.49mm
Diameter - Barrel ID 0.386 (9.80mm)
Diameter - Barrel OD 0.484 (12.29mm)
Diameter - Ring ID 0.354 (8.99mm)
Compliance
RoHS Status RoHS Compliant
