LCMAX120-10-L
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT RING 120MM #M10
PDF
/
Inventory: 2235
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Diameter - Ring ID 0.433 (11.00mm)
Diameter - Barrel OD 0.827 (21.01mm)
Diameter - Barrel ID 0.650 (16.51mm)
Tab Thickness 0.175 4.45mm
Width - Outer Edges 1.201 30.51mm
Length - Overall 2.776 70.50mm
Length 70.5104mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size M10 Stud
Terminal Type Ring, Tubular
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge 120mm2
Contact Finish Tin
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Series LCMAX
Published 2012
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
