LCMAX10-8-C
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT RING 10MM #M8
PDF
/
Inventory: 2439
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 2012
Series LCMAX
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
Contact Finish Tin
Wire Gauge 10mm2
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Ring, Tubular
Stud/Tab Size M8 Stud
Terminal Style Single Stud Hole
Dimensions
Length 34.4932mm
Length - Overall 1.358 34.50mm
Width - Outer Edges 0.512 13.00mm
Tab Thickness 0.047 1.19mm
Diameter - Barrel ID 0.217 (5.51mm)
Diameter - Barrel OD 0.283 (7.19mm)
Diameter - Ring ID 0.354 (8.99mm)
Compliance
RoHS Status RoHS Compliant
