LCD2-56B-Q
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 2AWG 67.3mm 16.8mm Tin
PDF
/
Buying Options
Total Price: USD $6.84
Unit Price: USD $6.8376
≥1 USD $6.8376
Inventory: 61
Minimum: 1
-
+
Technical Details
Technical
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 5/16 Stud
Terminal Style Two Stud Holes
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 2 AWG
Wire Gauge 2 AWG
Contact Finish Electro-Tin
HTS Code 8536.90.40.00
Color Brown
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk
Dimensions
Length 67.31mm
Length - Overall 2.650 67.31mm
Width - Outer Edges 0.660 16.76mm
Tab Thickness 0.100 2.54mm
Diameter - Barrel ID 0.310 (7.87mm)
Diameter - Barrel OD 0.420 (10.67mm)
Diameter - Ring ID 0.340 (8.64mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
