LCC600-12W-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (8.5/0)AWG 161.5mm 43.2mm Tin
PDF
/
Buying Options
Total Price: USD $42.42
Unit Price: USD $42.416
≥1 USD $42.416
≥10 USD $41.23856
≥100 USD $40.060416
≥500 USD $38.882272
≥1000 USD $37.703952
≥3000 USD $36.525738
Inventory: 137
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Green
HTS Code 8536.90.40.00
Depth 43.2mm
Contact Finish Electro-Tin
Wire Gauge 600MCM (kcmil)
Body Plating Tin
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 1/2 Stud
Terminal Style Two Stud Holes
Terminal Gender FEMALE
Dimensions
Length 161.544mm
Length - Overall 6.360 161.54mm
Width - Outer Edges 1.700 43.18mm
Tab Thickness 0.260 6.60mm
Diameter - Barrel ID 0.920 (23.37mm)
Diameter - Barrel OD 1.190 (30.23mm)
Diameter - Ring ID 0.530 (13.46mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
