LCC6-14BDW-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 6AWG 72.6mm 12.2mm Tin
PDF
/
Inventory: 4764
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Barrel OD 0.310 (7.87mm)
Diameter - Barrel ID 0.220 (5.59mm)
Tab Thickness 0.080 2.03mm
Width - Outer Edges 0.480 12.19mm
Length - Overall 2.860 72.64mm
Length 72.644mm
Technical
Terminal Style Two Stud Holes
Stud/Tab Size 1/4 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 6 AWG
Body Plating Tin
Wire Gauge 6 AWG
Contact Finish Electro-Tin
Depth 12.2mm
HTS Code 8536.90.40.00
Color Blue
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2005
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
