LCC400-14BWH-6

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description Lug Terminal (6.7/0)AWG 91.2mm 35.3mm Tin
PDF
/
Inventory: 2757
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Diameter - Ring ID 0.270 (6.86mm)
Diameter - Barrel OD 0.950 (24.13mm)
Diameter - Barrel ID 0.760 (19.30mm)
Tab Thickness 0.180 4.57mm
Width - Outer Edges 1.390 35.31mm

Technical

Terminal Style Two Stud Holes
Stud/Tab Size 1/4 Stud
Wire Cross Section 258 mm2
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge 400MCM (kcmil)
Contact Finish Electro-Tin
HTS Code 8536.90.40.00
Color Blue
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk

Physical

Mounting Type Free Hanging (In-Line), 45° Angle
Mount Free Hanging
Contact Plating Tin
Contact Material Copper

Supply Chain

Factory Lead Time 4 Weeks
