LCAX300-58F-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Pan-Lug? ROHS3Compliant 2004 Non-Insulated Terminal Rectangular Connector 35.3mm
PDF
/
Buying Options
Total Price: USD $70.5
Unit Price: USD $70.497478
≥1 USD $70.497478
≥200 USD $28.128883
≥500 USD $27.188846
≥1000 USD $26.725392
Inventory: 9704
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Red
HTS Code 8536.90.40.00
Depth 35.3mm
Contact Finish Electro-Tin
Wire Gauge 300MCM (kcmil)
Body Plating Tin
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 5/8 Stud
Terminal Style Single Stud Hole
Dimensions
Length 65.5mm
Width - Outer Edges 1.390 35.31mm
Tab Thickness 0.180 4.57mm
Diameter - Barrel ID 0.760 (19.30mm)
Diameter - Barrel OD 0.950 (24.13mm)
Diameter - Ring ID 0.660 (16.76mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
