LCA1/0-12F-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (1/0)AWG 46.2mm 20.3mm Tin
PDF
/
Buying Options
Total Price: USD $8.7
Unit Price: USD $8.7032
≥1 USD $8.7032
≥10 USD $8.47176
≥100 USD $7.765648
≥500 USD $7.295015
Inventory: 64
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Weight 362.873924g
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Pink
Gender Female
HTS Code 8536.90.40.00
Depth 20.3mm
Contact Finish Electro-Tin
Wire Gauge 1/0 AWG
Wire Gauge (Max) 0 AWG
Wire Gauge (Min) 1 AWG
Body Plating Tin
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 1/2 Stud
Terminal Style Single Stud Hole
Dimensions
Length 46.2mm
Width - Outer Edges 0.800 20.32mm
Tab Thickness 0.120 3.05mm
Diameter - Barrel ID 0.390 (9.91mm)
Diameter - Barrel OD 0.520 (13.21mm)
Diameter - Ring ID 0.530 (13.46mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
