1426-2
RoHS
RoHS compliant
RoHS compliantPackage 062
Category Connectors, Interconnects / Terminals - PC Pin, Single Post Connectors
Description
ROHS3Compliant 2005 Lead Free Non-Insulated PC Pin Terminal Connector 0.062 1.57mm
PDF
/
Buying Options
Total Price: USD $0.2
Unit Price: USD $0.2024
≥1 USD $0.2024
≥10 USD $0.16368
≥100 USD $0.1452
≥500 USD $0.135062
≥1000 USD $0.118184
≥3000 USD $0.092154
Inventory: 1620
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length - Above Flange 0.188 4.78mm
Length - Below Flange 0.078 1.98mm
Board Thickness 0.062 1.57mm
Length - Overall 0.291 7.39mm
Contact Finish Thickness 200.0μin 5.08μm
Length 7.3914mm
Technical
Pin Size - Above Flange 0.024 0.61mm Dia
Terminal Style Single End
Flange Diameter 0.060 (1.52mm)
Hole Diameter 889 μm
Terminal Type PC Pin
Insulation Non-Insulated
Contact Finish Tin
Connector Type INTERCONNECTION DEVICE
Termination Swage
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2005
Packaging Bulk
Physical
Mounting Hole Diameter 0.035 (0.89mm)
Package / Case 062
Mounting Type Through Hole
Mount Through Hole
Contact Material Brass
Supply Chain
Factory Lead Time 6 Weeks
