1406-4 image
Favorite
1406-4 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - PC Pin, Single Post Connectors
Description ROHS3Compliant 2000 Lead Free Non-Insulated PC Pin Terminal Connector 0.125 3.18mm
PDF
/
Buying Options
Total Price: USD $0.23
Unit Price: USD $0.228652
≥1 USD $0.228652
≥10 USD $0.215708
≥100 USD $0.203496
≥500 USD $0.191981
≥1000 USD $0.181114
Inventory: 6244
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks

Physical

Contact Material Brass
Mount Through Hole
Mounting Type Through Hole
Material Gold
Mounting Hole Diameter 0.035 (0.89mm)

Technical

Packaging Bulk
Published 2000
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Swage
Connector Type INTERCONNECTION DEVICE
Insulation Non-Insulated
Terminal Type PC Pin
Hole Diameter 889 μm
Flange Diameter 0.060 (1.52mm)
Terminal Style Single End
Pin Size - Above Flange 0.024 0.61mm Dia

Dimensions

Length 8.9916mm
Contact Finish Thickness 10.0μin 0.25μm
Length - Overall 0.354 9.00mm
Board Thickness 0.125 3.18mm
Length - Below Flange 0.141 3.58mm
Length - Above Flange 0.188 4.78mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
