RoHS
RoHS RoHS compliant
Package 125
Category Connectors, Interconnects / Terminals - PC Pin, Single Post Connectors
Description Circuit Board Hardware - PCB .075 x .125 PTFE Pin Pin Mtg Hole .113"
PDF
/
Buying Options
Total Price: USD $1.61
Unit Price: USD $1.6104
≥1 USD $1.6104
≥10 USD $1.369632
≥100 USD $1.250568
≥500 USD $1.160509
≥1000 USD $1.056
≥3000 USD $0.9152
Inventory: 388
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Length - Above Flange 0.200 5.08mm
Board Thickness 0.062 1.57mm
Diameter - Inside 3.2 mm
Length - Overall 0.225 5.72mm
Length 5.715mm

Technical

Pin Size - Above Flange 0.045 1.14mm Dia
Terminal Style Single End
Outside Diameter 3.8 mm
Flange Diameter 0.150 (3.81mm)
Hole Diameter 2.8702 mm
Terminal Type PC Pin
Insulation Insulated
Contact Finish Tin
Insulation Color White
Connector Type BOARD CONNECTOR
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2007
Packaging Bulk

Physical

Mounting Hole Diameter 0.113 (2.87mm)
Material - Insulation Polytetrafluoroethylene (PTFE)
Package / Case 125
Mounting Type Through Hole, Bottom Entry
Mount Solder, Through Hole
Contact Material Brass

Supply Chain

Factory Lead Time 6 Weeks
