LTC2996IDD#PBF
RoHS
RoHS compliant
RoHS compliantPackage 10-WFDFN Exposed Pad
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
THERMOSTAT 20/70DEG OPN DR 10DFN
PDF
/
Buying Options
Total Price: USD $5.73
Unit Price: USD $5.7288
≥1 USD $5.7288
≥10 USD $5.1788
≥100 USD $4.937856
≥500 USD $4.287422
≥1000 USD $4.094693
≥3000 USD $3.733409
Inventory: 130
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Body Height 0.75mm
Technical
Trip Temperature Threshold Cold Hot
Selectable Hysteresis No
Switching Temperature -20°C 70°C
Housing PLASTIC
Sensors/Transducers Type TEMPERATURE SENSOR,ANALOG,VOLTAGE OUTPUT
Output Function /OverTemp, /UnderTemp
Accuracy ±2°C
Nominal Supply Current 200μA
Operating Supply Current 200μA
Termination Type SOLDER
Interface I2C, Serial
Power Supplies 3.3V
Output Type Open Drain
Body Breadth 3 mm
Body Length or Diameter 3mm
Pin Count 10
Output Active High, Active Low
Base Part Number LTC2996
Voltage - Supply 2.25V~5.5V
Technology CMOS
Subcategory Other Sensors/Transducers
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Utilizes External Sensor
JESD-609 Code e3
Published 2012
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 10
Surface Mount YES
Package / Case 10-WFDFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 3 months ago)
Factory Lead Time 8 Weeks
