224ADVBAB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
Standard 224A Through Hole Top Actuated Tactile Switch 8.50mm 0.05A @ 12VDC 160gf -40C~85C
PDF
/
Inventory: 5322
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Through Hole
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2016
Series 224A
Feature Board Guide
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Termination Style PC Pin
Actuator Type Standard
Circuit SPST-NO
Switch Function Off-Mom
Illumination Non-Illuminated
Mechanical Life 500,000 Cycles
Switch Type KEYPAD SWITCH
Operating Force 160gf
Actuator Orientation Top Actuated
Outline 12.00mm x 12.00mm
Contact Rating @ Voltage 0.05A @ 12VDC
Switch Travel 0.30mm
Actuator Height off PCB, Vertical 8.50mm
Compliance
RoHS Status RoHS Compliant
