RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Switching Converter, SMPS Transformers
Description
VOIP FLYBACK XFORMER
PDF
/
Buying Options
Total Price: USD $2.23
Unit Price: USD $2.2264
≥1 USD $2.2264
≥10 USD $1.78024
≥100 USD $1.446368
≥500 USD $1.409232
≥1000 USD $1.372096
≥3000 USD $1.334995
Inventory: 1177
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.270 6.85mm
Technical
Footprint 0.386 L x 0.480 W (9.80mm x 12.20mm)
Inductance @ Frequency 3.38μH @ 100kHz
Transformer Type SMPS TRANSFORMER
DC Resistance (DCR) 450MOhm
Inductance 3.38 μH
Reach Compliance Code unknown
Applications Flyback Converters
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.386Lx0.343W 9.80mmx8.70mm
Series CEEH
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
