PH9185.011NL
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Transformers / Specialty Transformers
Description
Power Transformers TRANSFORMER 750UH 1:1 SMD
PDF
/
Buying Options
Total Price: USD $2.82
Unit Price: USD $2.816
≥1 USD $2.816
≥10 USD $2.28184
≥100 USD $1.844832
≥500 USD $1.72832
≥1000 USD $1.7094
Inventory: 5966
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SMD/SMT
Number of Pins 6
Weight 0.006lb 2.72g
Technical
Packaging Tray
Series PH9185
Size / Dimension 0.394Lx0.394W 10.00mmx10.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Capacitance 10pF
Depth 13mm
Inductance 750μH
DC Resistance (DCR) 500mOhm
Lead/Base Style Gull Wing
Isolation Voltage 5kV
Transformer Type SMPS TRANSFORMER
Turns Ratio - Primary:Secondary 1:1
Dimensions
Height 12.5mm
Height Seated (Max) 0.492 12.50mm
Compliance
RoHS Status RoHS Compliant
