NBSG16MN
RoHS
/
Package 16-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Specialized ICs
Description
Buffers & Line Drivers 2.5V/3.3V SiGe Diff
PDF
/
Buying Options
Total Price: USD $18.72
Unit Price: USD $18.722387
≥1 USD $18.722387
≥10 USD $17.662628
≥100 USD $16.662863
≥500 USD $15.719676
≥1000 USD $14.829889
Inventory: 2165
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 1mm
Technical
Transmit Delay-Max 0.145 ns
Receive Delay-Max 0.145 ns
Interface Standard GENERAL PURPOSE
Receiver Number of Bits 1
Driver Number of Bits 1
Input Characteristics DIFFERENTIAL
Differential Output YES
Data Rate 12 Gbps
Logic Function AND, Receiver
Nominal Supply Current 29mA
Min Supply Voltage 2.375V
Max Supply Voltage 3.465V
Temperature Grade INDUSTRIAL
Power Supplies +-2.5/+-3.3V
Qualification Status Not Qualified
JESD-30 Code S-XQCC-N16
Pin Count 16
Base Part Number NBSG16
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Terminal Pitch 0.5mm
Supply Voltage 2.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form NO LEAD
Terminal Position QUAD
Technology ECL
Subcategory Line Driver or Receivers
HTS Code 8542.39.00.01
Additional Feature NECL MODE: VCC = 0V WITH VEE = -2.375V TO -3.465V
Applications Instrumentation
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn90Pb10)
Type Transceiver
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Published 2008
Packaging Tube
Physical
Package / Case 16-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
