TLP222AF
RoHS
RoHS compliant
RoHS compliantPackage 4-DIP (0.300, 7.62mm)
Category Relays / Solid State Relays
Description
SSR RELAY SPST-NO 500MA 0-60V
PDF
/
Buying Options
Total Price: USD $7.26
Unit Price: USD $7.261
≥1 USD $7.261
≥10 USD $6.85
Inventory: 12
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Response Time-Max 0.002s
Isolation Voltage-Max 2500V
Load Current 500mA
On-State Current-Max 0.5A
Forward Voltage-Max 1.3V
On-State Resistance (Max) 2Ohm
Forward Current-Max 0.025A
Voltage - Load 0V~60V
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Voltage - Input 1.15VDC
Configuration SINGLE WITH BUILT-IN DIODE
Circuit SPST-NO (1 Form A)
Number of Elements 1
Output Type AC, DC
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Termination Style PC Pin
Subcategory Optocoupler - Transistor Outputs
HTS Code 8541.40.95.00
Additional Feature UL RECOGNIZED
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series TLP222A
Published 2009
Packaging Tube
Physical
Surface Mount NO
Package / Case 4-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Supply Chain
Factory Lead Time 12 Weeks
