40-6574-18
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
57 ROHS3Compliant 2005 RECTANGULAR DIP, ZIF (ZIP), 0.6 (15.24mm) Row Spacing Socket UL94V-0 250C 1A 1000VAC V
PDF
/
Buying Options
Total Price: USD $439.66
Unit Price: USD $439.663952
≥1 USD $439.663952
≥200 USD $175.428385
≥496 USD $169.566287
≥1000 USD $166.670029
Inventory: 6868
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyphenylene Sulfide (PPS), Glass Filled
Number of Positions or Pins (Grid) 40 (2 x 20)
Contact Material - Mating Beryllium Copper
Contact Material - Post Beryllium Copper
Technical
Packaging Bulk
Published 2005
Series 57
Feature Closed Frame
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type DIP, ZIF (ZIP), 0.6 (15.24mm) Row Spacing
Number of Positions 40
Additional Feature UL 94V-0
Contact Finish - Mating Tin
Terminal Pitch 2.54mm
Current Rating 1A
Pitch - Mating 0.100 2.54mm
Body Length or Diameter 2.59 inch
Number of Contacts 40
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 250°C
Body Breadth 0.9 inch
Lead Length 2.794mm
Body Depth 0.47 inch
Contact Style SQ PIN-SKT
Insulation Resistance 1000000000Ohm
Mating Contact Pitch 0.1 inch
Dielectric Withstanding Voltage 1000VAC V
PCB Contact Row Spacing 0.6 mm
Termination Post Length 0.110 2.78mm
Pitch - Post 0.100 2.54mm
Dimensions
Contact Finish Thickness - Mating 200.0μin 5.08μm
Contact Finish Thickness - Post 200.0μin 5.08μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
