46311LDR
RoHS
/
Package /
Category Switches / Slide Switches
Description
SWITCH SLIDE SP3T 3A 125V
PDF
/
Inventory: 7524
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Body Breadth 13.49 mm
Body Length or Diameter 42.06mm
Voltage - Rated AC 125V
Termination Style Solder Lug
Contact Finish Silver
Current Rating 3A
Current Rating (Amps) 3A AC 500mA DC
Voltage - Rated DC 125V
HTS Code 8536.50.90.50
Additional Feature UL,CSA WITH MOUNTING EARS
Number of Positions 3
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
JESD-609 Code e4
Series 46300R
Published 1998
Packaging Bulk
Operating Temperature -20°C~70°C
Switch Travel 6.25mm
Actuator Color BLACK
Contact (DC) Max Rating R Load .5A@125VDC
Contact Timing Non-Shorting (BBM)
Contact (AC) Max Rating R Load 3A@125VAC
Contact Current(AC)-Max 3A
Switch Type SLIDE SWITCH
Dielectric Withstanding Voltage 1000VRMS V
Contact Current(DC)-Max 0.5A
Insulation Resistance 1000000000Ohm
Contact Style Non-Shorting
Switch Function On-On-On
Circuit SP3T
Actuator Type Standard
Physical
Actuator Material Thermoplastic
Housing Material STEEL
Insulation Material PHENOLIC
Mounting Type Panel Mount
Mount Panel
Contact Material Copper Alloy
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Actuator Length 8.74mm
Length - Termination 0.312 inch
Body Height 8.33mm
