46256LFE
RoHS
/
Package /
Category Switches / Slide Switches
Description
SWITCH SLIDE DPDT 3A 125V
PDF
/
Inventory: 4740
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Mount Panel, Solder
Mounting Type Panel Mount
Housing Material Steel
Actuator Material Thermoplastic
Center Contact Plating SILVER
End Contact Plating SILVER
Technical
Operating Temperature -20°C~70°C
Packaging Bulk
Published 1998
Series 46200E
Feature 115V-230V Marking
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
ECCN Code EAR99
Type General Purpose
Number of Positions 2
Additional Feature UL AND CSA CERTIFIED
HTS Code 8536.50.90.50
Voltage - Rated DC 125V
Current Rating (Amps) 3A AC 500mA DC
Orientation Straight
Depth 13.49mm
Current Rating 3A
Termination Style Solder Lug
Voltage - Rated AC 125V
Actuator Type Screwdriver Slot
Circuit DPDT
Switch Function On-On (Line Voltage Selector)
Contact Style Non-Shorting
Insulation Resistance 1000000000Ohm
Contact Current(DC)-Max 0.5A
Max Voltage Rating (AC) 125V
Max Current Rating 3A
Dielectric Withstanding Voltage 1000VRMS V
Max Voltage Rating (DC) 125V
Contact Current(AC)-Max 3A
Contact (AC) Max Rating R Load 3A@125VAC
Contact Timing Non-Shorting (BBM)
Contact (DC) Max Rating R Load .5A@125VDC
Actuator Color BLACK
Switch Travel 4.78mm
Dimensions
Length 34.92mm
Body Height 11.12mm
Actuator Length Flush
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
