EG2219
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
SWITCH SLIDE DPDT 500MA 15V
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.9152
≥1 USD $0.9152
≥10 USD $0.88088
≥100 USD $0.822976
≥500 USD $0.714472
≥1000 USD $0.650179
≥3000 USD $0.602765
Inventory: 1850
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Copper Alloy
Mount Brackets, Through Hole
Mounting Type Through Hole, Right Angle
Technical
Operating Temperature -20°C~70°C
Packaging Bulk
Published 2002
Series EG
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Number of Positions 2
HTS Code 8536.50.90.50
Voltage - Rated DC 15V
Current Rating (Amps) 500mA DC
Orientation Right Angle
Current Rating 500mA
Contact Finish Silver
Termination Style PC Pin
Body Length or Diameter 13.8mm
Body Breadth 6.5 mm
Actuator Type Standard
Circuit DPDT
Switch Function On-On
Contact Style Non-Shorting
Insulation Resistance 100000000Ohm
Dielectric Withstanding Voltage 500VAC V
Electrical Life 10000 cycles
Switch Type SLIDE SWITCH
Contact Current Rating 500mA
Operating Force 250gf
Illumination Type Non-Illuminated
Contact Timing Non-Shorting (BBM)
PCB Hole Count 10
Contact Function ON-OFF
Switch Travel 4.00mm
Dimensions
Body Height 8.5mm
Length - Termination 0.138 inch
Actuator Length 9.00mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
