RSC141D1900
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER SPST 20A 125V
PDF
/
Inventory: 6920
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Plating Silver
Mounting Type Panel Mount, Snap-In
Surface Mount NO
Insulation Material POLYAMIDE
Actuator Material POLYAMIDE
Center Contact Material COPPER
End Contact Material COPPER
Technical
Operating Temperature -20°C~105°C
Packaging Bulk
Published 2011
Series RSC, LAMB
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Color Black, Red
Current Rating (Amps) 20A AC
Current Rating 20A
Termination Style Quick Connect - 0.250 (6.3mm)
Voltage - Rated AC 125V
Body Length or Diameter 28.4988mm
Body Breadth 13.7922 mm
Actuator Type Concave (Curved)
Circuit SPST
Switch Function On-Off
Panel Cutout Dimensions Rectangular - 28.60mm x 13.90mm
Contact Resistance 0.02mOhm
Insulation Resistance 100000000Ohm
Color - Actuator/Cap Red
Dielectric Withstanding Voltage 1000VAC V
Electrical Life 10,000 Cycles
Switch Type ROCKER SWITCH
Contact Current(AC)-Max 16A
Contact (AC) Max Rating R Load 16A@250VAC
Contact Voltage(AC)-Max 250V
Actuator Marking No Marking
Contact Function OFF-ON
Contact (AC) Max Power Rating R Load 0.25HP@125VAC
Dimensions
Body Height 18.4912mm
Length - Termination 0.378 inch
Actuator Length 0.307 inch
Compliance
RoHS Status ROHS3 Compliant
