RR3405A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER DPST 10A 125V
PDF
/
Buying Options
Total Price: USD $2.31
Unit Price: USD $2.3056
≥1 USD $2.3056
≥10 USD $2.06184
≥100 USD $1.956416
≥500 USD $1.860672
≥1000 USD $1.774256
≥3000 USD $1.697546
Inventory: 275
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 18.5mm
Length 24mm
Height 15mm
Technical
Actuator Angle 26 deg
Actuator Marking No Marking
Contact Voltage(AC)-Max 250V
Contact (AC) Max Rating R Load 6A@250VAC
Contact Current(AC)-Max 6A
Contact Current Rating 10A
Switch Type ROCKER SWITCH
Throw Configuration DPST, SPST
Dielectric Withstanding Voltage 1500VAC V
Color - Actuator/Cap Black
Insulation Resistance 100000000Ohm
Contact Resistance 0.05mOhm
Panel Cutout Dimensions Circular - 18.00mm Dia
Switch Function On-Off
Circuit DPST
Actuator Type Paddle
Voltage - Rated AC 125V
Termination Style Solder Lug
Current Rating 10A
Orientation Vertical
Current Rating (Amps) 10A AC
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series RR3405
Published 2001
Packaging Bulk
Physical
Mounting Type Panel Mount, Threaded Body with Nut
Mount Panel
Contact Material Silver
Supply Chain
Factory Lead Time 10 Weeks
