RR3130ABLKBLKES
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER SPST 10A 125V
PDF
/
Buying Options
Total Price: USD $2.75
Unit Price: USD $2.7456
≥1 USD $2.7456
≥10 USD $2.46312
≥100 USD $2.11112
≥500 USD $1.770595
Inventory: 1785
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Body Height 15mm
Technical
Actuator Marking No Marking
Hole Diameter 13.6 mm
Contact (AC) Max Rating R Load 10A@125VAC
Illumination Type Illuminated
Contact Current Rating 10A
Switch Type ROCKER SWITCH
Mechanical Life 20,000 Cycles
Electrical Life 6,000 Cycles
Max Voltage Rating (AC) 250V
Color - Actuator/Cap Black
Contact Resistance 50mOhm
Panel Cutout Dimensions Circular - 18.20mm Dia
Switch Function On-Off
Circuit SPST
Actuator Type Round
Voltage - Rated AC 125V
Termination Style Solder Lug
Current Rating 10A
Orientation Straight
Current Rating (Amps) 10A AC
ECCN Code EAR99
Termination Lug
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series RR3130
Published 2004
Packaging Bulk
Operating Temperature 0°C~65°C
Physical
Mounting Type Panel Mount, Threaded Body with Nut
Mount Panel
Contact Material Silver
Supply Chain
Factory Lead Time 10 Weeks
