R5BBLKREDFF2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER DPST 20A 125V
PDF
/
Buying Options
Total Price: USD $2.96
Unit Price: USD $2.9568
≥1 USD $2.9568
≥10 USD $2.6488
≥100 USD $2.512928
≥500 USD $2.389842
≥1000 USD $2.278962
≥3000 USD $2.180438
Inventory: 578
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Silver
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Actuator Material Polycarbonate
Technical
Operating Temperature -20°C~55°C
Packaging Bulk
Published 2008
Series R5
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Faston
ECCN Code EAR99
Current Rating (Amps) 20A AC
Orientation Straight
Current Rating 20A
Termination Style Quick Connect - 0.250 (6.3mm)
Voltage - Rated AC 125V
Actuator Type Concave (Curved) - Illuminated
Housing Color Black
Circuit DPST
Switch Function On-Off
Panel Cutout Dimensions Rectangular - 30.00mm x 22.20mm
Contact Resistance 20mOhm
Color - Actuator/Cap Red
Illumination Voltage (Nominal) 250VAC
Illumination Type, Color Neon, Red
Max Voltage Rating (AC) 250V
Electrical Life 10,000 Cycles
Max Voltage Rating (DC) 250V
Mechanical Life 30,000 Cycles
Switch Type ROCKER SWITCH
Contact Current Rating 20A
Illumination Type Illuminated, Neon
Actuator Marking O -
Dimensions
Height 17.1mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
