400MSP3R1BLKM1RE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER SPDT 0.4VA 20V
PDF
/
Inventory: 3487
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Body Height 8.43mm
Technical
Actuator Marking No Marking
Contact (DC) Max Rating R Load .02A@20VDC
Contact (AC) Max Rating R Load .02A@20VAC
Contact Current(AC)-Max 0.02A
Switch Type ROCKER SWITCH
Electrical Life 30,000 Cycles
Sealing EPOXY TERMINAL SEALED
Contact Current(DC)-Max 0.02A
Color - Actuator/Cap Black
Panel Cutout Dimensions Rectangular - 15.75mm x 8.89mm
Switch Function On-Off-On
Circuit SPDT
Actuator Type Concave (Curved)
Body Breadth 5.08 mm
Body Length or Diameter 8.13mm
Voltage - Rated AC 20V
Termination Style Solder Lug
Current Rating 400mA
Current Rating (Amps) 0.4VA AC/DC
HTS Code 8536.50.90.65
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
JESD-609 Code e4
Series 400
Published 2007
Packaging Tray
Operating Temperature -30°C~85°C
Physical
Housing Material Stainless Steel
Surface Mount NO
Mounting Type Panel Mount, Flange
Contact Plating Gold
Supply Chain
Factory Lead Time 9 Weeks
