E101J1A3QE2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER SPDT 7.5A 125V
PDF
/
Buying Options
Total Price: USD $10.74
Unit Price: USD $10.736
≥1 USD $10.736
≥10 USD $9.69848
≥100 USD $9.2312
Inventory: 41
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 16.87mm
Technical
Actuator Marking No Marking
Illumination Type Illuminated
Max Voltage Rating (DC) 28V
Electrical Life 40,000 Cycles
Max Current Rating 7.5A
Max Voltage Rating (AC) 250V
Color - Actuator/Cap Black
Switch Function On-On
Circuit SPDT
Actuator Type Concave (Standard V)
Voltage - Rated AC 125V
Termination Style PC Pin
Current Rating 7.5A
Depth 25.45mm
Orientation Right Angle
Current Rating (Amps) 7.5A AC/DC
Voltage - Rated DC 28V
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Sealed - Flux Protection
Series E
Published 2010
Packaging Tray
Operating Temperature -30°C~85°C
Physical
Actuator Material Nylon
Mounting Type Through Hole, Right Angle
Mount Brackets, Through Hole
Contact Material Silver
Supply Chain
Factory Lead Time 16 Weeks
