TXE-433-KH
RoHS
/
Package 24-SMD Module
Category RF/IF and RFID / RF Transmitters
Description
RF TX IC ASK 433.92MHZ 24SMD MOD
PDF
/
Inventory: 5392
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 24-SMD Module
Surface Mount NO
Technical
Operating Temperature -30°C~70°C
Packaging Tube
Published 2001
Series KH
Feature Built-in Remote Control Encoder
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
Applications Garage Openers, RKE, Security Alarms
Subcategory Remote Control ICs
Voltage - Supply 2.7V~5.2V
Terminal Position DUAL
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54mm
Reach Compliance Code unknown
Frequency 433.92MHz
JESD-30 Code R-PDIP-T24
Qualification Status Not Qualified
Power Supplies 3/5V
Data Interface PCB, Surface Mount
Power - Output -4dBm~4dBm
Consumer IC Type REMOTE CONTROL TRANSMITTER IC
Current - Transmitting 1.5mA
Modulation or Protocol ASK, OOK
Antenna Connector PCB, Surface Mount
Dimensions
Length 31.3mm
Width 16.2mm
Thickness 4.6mm
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
