CYBLE-013025-00
RoHS
RoHS compliant
RoHS compliantPackage 31-SMD Module
Category RF/IF and RFID / RF Transceiver Modules
Description
IC RF TXRX+MCU BLE 4.1 31SMT
PDF
/
Buying Options
Total Price: USD $5.5
Unit Price: USD $5.5
≥1 USD $5.5
≥10 USD $5.04504
≥100 USD $4.586208
≥500 USD $4.127552
≥1000 USD $3.783613
Inventory: 396
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 14.52mm
Length 19.2mm
Height Seated (Max) 2.25mm
Technical
Modulation GFSK
Current - Transmitting 22mA
Current - Receiving 26mA
Serial Interfaces I2C, SPI, UART
Sensitivity -94dBm
Antenna Type Integrated, Trace
RF Family/Standard Bluetooth
Power - Output 4dBm
Telecom IC Type TELECOM CIRCUIT
Protocol Bluetooth v4.1
Data Rate 1.5Mbps
Memory Size 128kB Flash 60kB SRAM
JESD-30 Code R-XXMA-N31
Frequency 2.402GHz~2.48GHz
Terminal Pitch 1.27mm
Number of Functions 1
Terminal Form NO LEAD
Terminal Position UNSPECIFIED
Voltage - Supply 2.3V~3.6V
Number of Terminations 31
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series EZ-BLE? PRoC?
Packaging Tape & Reel (TR)
Operating Temperature -30°C~85°C TA
Physical
Surface Mount YES
Package / Case 31-SMD Module
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
