PE42440MLBB-Z
RoHS
RoHS compliant
RoHS compliantPackage 16-WFQFN Exposed Pad
Category RF/IF and RFID / RF Switches
Description
RF Switch SP4T 50MHz to 3GHz 20dB 16-Pin QFN EP T/R
PDF
/
Buying Options
Total Price: USD $1.28
Unit Price: USD $1.2848
≥1 USD $1.2848
≥10 USD $1.1704
≥100 USD $1.0648
Inventory: 46119
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
IIP3 66dBm
P1dB 41.5dBm
RF Type General Purpose
Insertion Loss (dB) 1.15 dB
Isolation 22dB
Insertion Loss 0.85dB
Frequency Range 50MHz~3GHz
Topology Reflective
Throw Configuration SP4T
Impedance 50Ohm
Test Frequency 3GHz
Circuit SP4T
Operating Supply Voltage 2.75V
Frequency 3GHz
Voltage - Supply 2.65V~3.3V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature DC Blocked
Series UltraCMOS?, HaRP?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Supplier Device Package 16-QFN (3x3)
Number of Pins 16
Package / Case 16-WFQFN Exposed Pad
Supply Chain
Factory Lead Time 16 Weeks
