HMC495LP3
RoHS
/
Package 16-VFQFN Exposed Pad
Category RF/IF and RFID / RF Modulators
Description
Modulator / Demodulator SiGe Direct Mod , 250 - 3800 MHz
PDF
/
Inventory: 1429
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 1mm
Technical
Noise Floor -158dBm/Hz
LO Frequency 250MHz~3.8GHz
RF Frequency 250MHz~3.8GHz
P1dB 2dBm
Telecom IC Type RF AND BASEBAND CIRCUIT
Max Frequency 3.8GHz
Output Power -6dBm
Operating Supply Current 108mA
Temperature Grade INDUSTRIAL
Operating Supply Voltage 3.3V
Qualification Status Not Qualified
Function Modulator
Base Part Number HMC495
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 235
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 3V~3.6V
Max Power Dissipation 2.83W
HTS Code 8542.39.00.01
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Strip
Physical
Weight 57.09594mg
Number of Pins 16
Surface Mount YES
Package / Case 16-VFQFN Exposed Pad
Supply Chain
Lifecycle Status LAST TIME BUY (Last Updated: 5 days ago)
