MAX2321EUP+T

Maxim Integrated
RoHS
RoHS RoHS compliant
Package 20-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description IC LNA/MIXER SIGE ADJ 20TSSOP
PDF
/
Inventory: 2305
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Noise Figure-Max 13.5 dB
Down Conversion Gain-Min 9.6 dB
LO Tunable YES
Secondary Attributes With LO Doubler
Characteristic Impedance 50Ohm
RF Type CDMA, GSM, PDC, TDMA, WCDMA
RF/Microwave Device Type DOWN CONVERTER
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Function Dual Band LNA/Mixer
Frequency 800MHz~1GHz 1.8GHz~2.5GHz
Construction COMPONENT
Terminal Finish Matte Tin (Sn)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2006
Packaging Tape & Reel (TR)

Physical

Package / Case 20-TSSOP (0.173, 4.40mm Width) Exposed Pad
Mounting Type Surface Mount
