HMC1030LP5E
RoHS
RoHS compliant
RoHS compliantPackage 32-VFQFN Exposed Pad
Category RF/IF and RFID / RF Detectors
Description
RF Detector Dual RMS pow Det , SE, DC - 3.9 GHz
PDF
/
Buying Options
Total Price: USD $23.94
Unit Price: USD $23.9448
≥1 USD $23.9448
≥10 USD $22.08536
≥100 USD $21.092896
Inventory: 91
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 1mm
Technical
Input Range -55dBm ~ 15dBm
RF Type General Purpose
Telecom IC Type TELECOM CIRCUIT
Accuracy ±1dB
Element Configuration Dual
Operating Supply Current 143mA
Temperature Grade INDUSTRIAL
Operating Supply Voltage 5V
Pin Count 32
Base Part Number HMC1030
Time@Peak Reflow Temperature-Max (s) 30
Frequency 0Hz~3.9GHz
Terminal Pitch 0.5mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 4.5V~5.5V
Max Power Dissipation 2.21W
HTS Code 8542.39.00.01
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 32
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Packaging Strip
Physical
Weight 188.609377mg
Number of Pins 32
Surface Mount YES
Package / Case 32-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 3 weeks ago)
Factory Lead Time 8 Weeks
