SGA-2263
RoHS
/
Package 6-TSSOP, SC-88, SOT-363
Category RF/IF and RFID / RF Amplifiers
Description
IC AMP CELLULAR 0HZ-5GHZ SOT363
PDF
/
Buying Options
Total Price: USD $20.14
Unit Price: USD $20.1362
≥1 USD $20.1362
≥10 USD $16.5224
≥100 USD $16.0056
≥500 USD $15.48975
≥1000 USD $14.97295
Inventory: 7002
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Thickness 950μm
Width 1.25mm
Length 2mm
Technical
P1dB 6.1dBm
Noise Figure 3.5dB
Characteristic Impedance 50Ohm
Input Power-Max (CW) 18dBm
RF Type Cellular, GSM, PCS, UMTS
RF/Microwave Device Type WIDE BAND LOW POWER
Gain 13.5dB
Nominal Supply Current 20mA
Operating Supply Current 23mA
Test Frequency 1.95GHz
Power Supplies 2.2V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Frequency 0Hz~5GHz
Construction COMPONENT
Number of Functions 1
Voltage - Supply 1.9V~2.5V
Technology BIPOLAR
Subcategory RF/Microwave Amplifiers
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Published 2008
Packaging Tape & Reel (TR)
Physical
Surface Mount YES
Package / Case 6-TSSOP, SC-88, SOT-363
Mounting Type Surface Mount
