M90-7040845
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
Headers & Wire Housings IP68 HotShoe Conn 8P, TAIL, MALE
PDF
/
Inventory: 9043
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Flanges, Panel, Through Hole
Mounting Type Panel Mount, Flange; Through Hole
Material Brass
Housing Material Polyamide
Technical
Packaging Bulk
Published 2011
Series HotShoe
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Through Hole
ECCN Code EAR99
Connector Type Mating Target
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Number of Rows 2
Voltage - Rated 240V
Subcategory Headers and Edge Type Connectors
Pitch 0.098 2.50mm
Current Rating 1A
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Number Of PCB Rows 2
Number of Contacts 8
PCB Contact Pattern RECTANGULAR
Body Breadth 0.709 inch
Contact Gender Male
Rated Current (Signal) 1A
Contact Style RND PIN-SKT
Contact Resistance 10mOhm
Insulation Resistance 1GOhm
Row Spacing 0.098 (2.50mm)
Polarization Key POLARIZED HOUSING
Contact Pattern RECTANGULAR
Insulator Color BLACK
Insulation Insulated
Dimensions
Height 18mm
Length 37mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
