92009-5
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Rectangular Connector Housing
PDF
/
Inventory: 7898
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Insulation Diameter-Min 0.039 inch
Wire Size (Max) 22 AWG
Wire Size (Min) 30 AWG
Contact Design PREASSEM CONN
Contact Pattern RECTANGULAR
Polarization Key POLARIZED HOUSING
ELV Compliant
Contact Resistance 20mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Body Depth 0.378 inch
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 5
Reference Standard UL
Orientation Straight
Pitch 2.5mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Gender Female
Number of Rows 1
Color Natural
Connector Type Receptacle, Socket
ECCN Code EAR99
Termination Crimp
Pbfree Code yes
Packaging Bulk
Physical
Housing Material Nylon
Mount Free Hanging
Contact Material Bronze
