5-582151-4
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Standard Card Edge Connectors 35 AMP BLADE RCPT HSG/MIL
PDF
/
Inventory: 2058
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Preloaded No
Withdrawl Force-Min 4.448 N
Insertion Force-Max .556 N
Contact Pattern STAGGERED
PCB Contact Row Spacing 3.175 mm
Polarization Key POLAR PIN POSITION
Termination Type CRIMP
ELV Compliant
Body/Shell Style RECEPTACLE
Contact Style BLADE PIN-SKT
Rated Current (Signal) 5A
Body Depth 0.745 inch
Housing Color Green
Operating Temperature (Min) -65°C
Body Breadth 0.4 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern STAGGERED
Number of Contacts 35
Number Of PCB Rows 2
Body Length or Diameter 4.19 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Military Standard MIL-DTL-21097
Orientation Straight
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature TERMI-POINT, PANEL MOUNTABLE
Gender Female
Number of Rows 2
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Pbfree Code yes
Physical
Mounting Option 1 LOCKING
Insulation Material GLASS FILLED DIALLYL PHTHALATE
Mounting Type CABLE
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
