316768-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
POWER DBL LOCK PLUG HSG 1P RED
PDF
/
Buying Options
Total Price: USD $0.34
Unit Price: USD $0.340041
≥1 USD $0.340041
≥10 USD $0.278335
≥30 USD $0.252077
Inventory: 13
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mounting Type CABLE
Shell Material POLYAMIDE66
Housing Material Nylon
Technical
Pbfree Code yes
Connector Type Socket
Max Operating Temperature 221°C
Min Operating Temperature -22°C
Number of Rows 1
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.9624mm
Total Number of Contacts 1
Approval Agency CSA
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender MALE
Housing Color Red
Empty Shell NO
Operating Supply Voltage 300V
Body/Shell Style PLUG
ELV Compliant
Wire/Cable Type Discrete
Sealable No
Number of Power Positions 0
Contact Retention Without
VDE Tested Yes
Dimensions
Height 20.6mm
Length 20.6mm
Width 5.98mm
Compliance
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
