174147-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Automotive Connectors 070 MULTILK PLUG 16P
PDF
/
Buying Options
Total Price: USD $1.44
Unit Price: USD $1.436313
≥1 USD $1.436313
≥10 USD $1.256445
≥30 USD $1.142223
Inventory: 18
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Contact Material Bronze
Contact Plating Tin
Mount Cable, Free Hanging
Housing Material Polybutylene
Body Material PBT
Technical
Published 1997
Pbfree Code yes
Part Status Active
Termination Crimp
Connector Type Plug, Socket
Max Operating Temperature 221°C
Min Operating Temperature -22°C
Color Black
Number of Rows 2
Gender Male
Fastening Type Latch
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.81mm
Orientation Straight
Depth 21mm
Current Rating 14A
Row Spacing - Mating 2.9972 mm
Number of Contacts 16
Contact Gender Female
Empty Shell NO
ELV Compliant
Wire/Cable Type Discrete
Circuit Application Signal
Mating Tab Width 1.8mm
Hybrid Connector No
Polarized Yes
Dimensions
Height 26.3906mm
Length 21mm
Width 31.6992mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 HB
