44133-0600
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN RECEPT 6POS 3MM DUAL ROW
PDF
/
Buying Options
Total Price: USD $0.33
Unit Price: USD $0.326332
≥1 USD $0.326332
≥10 USD $0.307868
≥100 USD $0.290444
≥500 USD $0.273999
≥1000 USD $0.258494
Inventory: 8730
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Material Bronze
Contact Plating Tin
Mount Cable, Panel
Housing Material Polyester
Technical
Packaging Bulk
Published 2006
Pbfree Code yes
Part Status Active
Termination Crimp
Connector Type Receptacle, Socket
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Black
Number of Rows 2
Additional Feature MICRO-FIT 3.0, BMI, PANEL MOUNTABLE
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3mm
Orientation Straight
Depth 16mm
Current Rating 5A
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Row Spacing - Mating 2.9972 mm
Number of Contacts 6
Contact Gender Female
UL Flammability Code 94V-0
Operating Supply Voltage 250V
Contact Resistance 10mOhm
Insulation Resistance 1GOhm
Max Voltage Rating (AC) 250V
Max Voltage Rating (DC) 176.25kV
Withdrawl Force-Min 3.5584 N
Glow Wire Compliant Non-compliant
Dimensions
Length 27.7mm
Width 15.2mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
