22-01-1074
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN RCPT HOUSING 7POS 2.5MM
PDF
/
Inventory: 5789
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material NOT SPECIFIED
Mount Cable, Free Hanging
Housing Material Nylon
Technical
Packaging Bulk
Termination Crimp
ECCN Code EAR99
Connector Type Crimp, Receptacle, Socket
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Natural
Number of Rows 1
Voltage - Rated 250V
HTS Code 8536.69.40.40
Fastening Type Ramp
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.5mm
Orientation Straight
Depth 10.7mm
Current Rating 3A
Reference Standard UL, CSA
Reliability COMMERCIAL
Number of Contacts 7
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.26 inch
Contact Gender Female
UL Flammability Code 94V-0
Rated Current (Signal) 3A
Contact Resistance 20mOhm
Body/Shell Style PLUG
Polarization Key POLARIZED RIB(S)
Max Voltage Rating (DC) 250.25kV
Contact Pattern RECTANGULAR
Wire Size (Min) 28 AWG
Wire Size (Max) 22 AWG
Glow Wire Compliant Non-compliant
Dimensions
Length 20mm
Width 6.6mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
