15-97-5081
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN RCPT 8POS DUAL MINI-FIT
PDF
/
Buying Options
Total Price: USD $0.6
Unit Price: USD $0.600797
≥1 USD $0.600797
≥10 USD $0.566786
≥100 USD $0.534706
≥500 USD $0.50444
≥1000 USD $0.475885
Inventory: 1367
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Length 20.27mm
Technical
Insulation Diameter-Min 0.035 inch
Glow Wire Compliant Non-compliant
Wire Size (Max) 16 AWG
Withdrawl Force-Min 3.1136 N
Contact Pattern RECTANGULAR
Max Voltage Rating (DC) 600.6kV
Durability 30 Cycles
Polarization Key CENTER
Max Voltage Rating (AC) 600V
Insulation Resistance 1000000000Ohm
Contact Resistance 5mOhm
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender Female
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 8
Row Spacing - Mating 5.5118 mm
Reliability COMMERCIAL
Reference Standard UL, CSA
Current Rating 13A
Depth 19.6mm
Orientation Straight
Pitch 4.2mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Latch
Gender Receptacle
Number of Rows 2
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type Receptacle, Socket
ECCN Code EAR99
Termination Crimp
Part Status Active
Pbfree Code yes
Published 2010
Packaging Bulk
Physical
Housing Material Polyester
Mount Cable, Free Hanging
Supply Chain
Factory Lead Time 8 Weeks
