M80-1032098S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CRIMP HOUSING, 2 ROW, 20WAY
PDF
/
Buying Options
Total Price: USD $3.27
Unit Price: USD $3.2736
≥1 USD $3.2736
≥10 USD $2.97352
≥100 USD $2.6202
≥500 USD $2.227157
≥1000 USD $1.89963
≥3000 USD $1.703117
Inventory: 484
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 5.4mm
Length 23mm
Technical
Contact Design PREASSEM CONN
Contact Termination Crimp
Body/Shell Style PLUG
Note Contacts Not Included
Row Spacing 0.079 (2.00mm)
Insulation Resistance 100mOhm
Working Voltage 120V
UL Flammability Code 94V-0
Reliability COMMERCIAL
Voltage - Rated AC 120V
Reference Standard UL
Number of Conductors ONE
Current Rating 3.3A
Depth 7.55mm
Orientation Straight
Total Number of Contacts 20
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 120V
Subcategory Headers and Edge Type Connectors
Fastening Type Latch Holder
Additional Feature ROHS COMPLIANT
Number of Rows 2
Color Black
Number of Positions 20
Connector Type Receptacle
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series Datamate L-Tek
Published 2006
Packaging Bulk
Physical
Mounting Option 1 LOCKING
Housing Material Polyester
Material Glass, Thermoplastic
Mounting Type Free Hanging (In-Line)
Supply Chain
Factory Lead Time 9 Weeks
