530778-1

TE Connectivity
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description Rectangular MIL Spec Connectors 2R BOX RECP 30P 100 C/L
PDF
/
Inventory: 7939
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Not Applicable
RoHS Status RoHS Compliant

Dimensions

Length - Termination 0.405 inch

Technical

Contact Pattern RECTANGULAR
Polarization Key ENDS
ELV Compliant
Contact Style SQ PIN-SKT
Body Depth 0.4 inch
Lead Length 10.29mm
Contact Gender Female
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Reliability COMMERCIAL
Number of Conductors ONE
Military Standard MIL-DTL-55302
Orientation Vertical
Total Number of Contacts 30
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Rows 2
Color Blue
Number of Positions 30
Connector Type Connector, Receptacle, Socket
ECCN Code EAR99
Termination Solder
Part Status Discontinued
Pbfree Code yes
Published 1997
Packaging Bulk

Physical

Contact Shape Square
Mount Through Hole
Contact Plating Gold
Contact Material Copper

Supply Chain

Factory Lead Time 14 Weeks
