79109-0019
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN RECEPT 40POS 2MM VERT SMD
PDF
/
Inventory: 9290
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Gold
Mount Surface Mount
Housing Material Thermoplastic
Technical
Termination Solder
ECCN Code EAR99
Connector Type Receptacle, Socket
Number of Positions 40
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Color Black
Number of Rows 2
Voltage - Rated 125V
Additional Feature MILL-GRID, BOTTOM ENTRY/TOP ENTRY, POLARIZED
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2mm
Total Number of Contacts 40
Orientation Vertical
Current Rating 1A
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Row Spacing - Mating 2.0066 mm
Number Of PCB Rows 2
Lead Pitch 2mm
PCB Contact Pattern RECTANGULAR
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.165 inch
Contact Gender Female
UL Flammability Code 94V-0
Body Depth 0.175 inch
Rated Current (Signal) 1A
Contact Style SQ PIN-SKT
Contact Resistance 25mOhm
Insulation Resistance 1000000000Ohm
Polarization Key POLAR PIN POSITION
Dielectric Withstanding Voltage 500VDC V
PCB Contact Row Spacing 5.08 mm
Durability 50 Cycles
Max Voltage Rating (DC) 125.125kV
Contact Pattern RECTANGULAR
Withdrawl Force-Min .417 N
Dimensions
Plating Thickness 15μin
Compliance
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
