1-644894-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Rectangular Connector Header
PDF
/
Inventory: 2649
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Number of Conductors ONE
Reference Standard UL, CSA
Voltage - Rated AC 250V
Reliability COMMERCIAL
Shrouding Yes
Number Of PCB Rows 1
Number of Contacts 12
PCB Contact Pattern RECTANGULAR
HTS Code 8536.69.40.40
Gender Male
Number of Rows 1
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Termination Solder
Pbfree Code no
Packaging Bulk
Insertion Force-Max 8.896 N
Contact Pattern RECTANGULAR
ELV Non-Compliant
Body/Shell Style PLUG
Contact Style SQ PIN-SKT
Housing Color Black
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Physical
Housing Material Polyester
Mount Through Hole
Contact Plating Lead, Tin
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
